LED Aluminum Panel Light 600x1200 aluminum frame panel on white

LED Aluminum Panel Light 300×450-600×1200 36W-120W 3000K-6500K 85-265V

Six Size Options: Choose 300×450, 450×450, 450×900, 200×1200, 300×1200 or 600×1200 mm formats.
Wide Power Range: 36W to 120W covers small rooms through large open-plan areas.
Three CCT Choices: 3000K, 4000K and 6500K suit warm, neutral and cool white projects.
Universal Voltage: AC 85-265V input supports 110V and 220-240V markets.
Durable Aluminum Frame: Metal rim resists bending and acts as a passive heat sink.

Etiquetas:

Indoor light, Painel luminoso

Partilhar ：

DESCRIÇÃO DO PRODUTO

The LED Aluminum Panel Light is a versatile ceiling solution built in six different sizes, giving contractors a single product family for everything from small corridors to large open-plan offices.

Why Choose the LED Aluminum Panel Light?

Every version of the LED Aluminum Panel Light shares the same aluminum frame construction. The frame resists bending during transport and installation, while the laminated steel backing and PS diffuser create a flat, even light surface. This combination is ideal for projects where panels are handled in large quantities and fitted into suspended ceilings quickly. The series covers a wide size range. Buyers can choose 300 by 450 mm, 450 by 450 mm, 450 by 900 mm, 200 by 1200 mm, 300 by 1200 mm or 600 by 1200 mm formats. Each size uses a matched LED bead count and driver to deliver consistent brightness across the diffuser. Because the thickness stays at 30 mm for every model, ceiling void depth remains predictable on site. Power options scale from 36 W on the smallest panel up to 120 W on the largest. Intermediate sizes provide 48 W, 60 W, 80 W and additional 48 W configurations to match different room heights and lighting level requirements. Installers can mix sizes within the same project while keeping the same visual style and mounting method. Color temperature is available in 3000 K, 4000 K and 6500 K. Warm white creates relaxed waiting and lounge areas. Neutral white supports focused office work. Cool daylight is well suited to workshops, laboratories and circulation zones. The LED Aluminum Panel Light lets specifiers match each space to its function without switching product lines. Voltage input is rated AC 85-265 V. This wide range covers both 110 V and 220-240 V markets, so export buyers can use one SKU list across multiple countries. It also tolerates minor grid fluctuations, which reduces the risk of early driver failure in older buildings.

Construction and Performance

The aluminum frame acts as a heat sink as well as a structural rim. Heat from the LED board spreads into the metal profile and dissipates into the ceiling void. Passive cooling keeps the design simple and avoids the noise or maintenance issues associated with active cooling. The PS diffuser softens the output and hides individual LED points. Occupants see a smooth glowing plane rather than a grid of bright dots. This improves visual comfort in spaces where people spend many hours under artificial light, such as offices, schools and hospitals. The integrated driver is protected within the panel housing. There is no external ballast to mount or wire separately, which speeds up retrofit work. The LED Aluminum Panel Light can replace existing fluorescent troffers using the same ceiling grid without major rewiring.

Installation and Application

Office projects often use the 600 by 1200 mm and 300 by 1200 mm panels in open work areas. The 450 by 900 mm and 200 by 1200 mm formats suit corridors and transition spaces. Smaller 300 by 450 mm and 450 by 450 mm units work in meeting rooms, toilets and storage areas. Retail stores use the larger sizes above aisles and display counters. The clean aluminum bezel creates a continuous ceiling line that does not distract from merchandise. Color temperature can be selected to make products look natural and appealing. Healthcare and educational buildings value the even light and low glare. The flat diffuser reduces eye strain during long reading or computer sessions. Maintenance teams benefit from the standard sizes because replacement panels fit existing T-bar grids without custom adapters. Across all of these spaces, the LED Aluminum Panel Light delivers a clean, uniform ceiling appearance.

Ordering and Project Support

Each panel is packed by size, wattage and color temperature for easy warehouse picking. Mixed orders are supported, so a single shipment can cover an entire building fit-out. Custom labeling and carton printing are available for distributor and contractor brands. The LED Aluminum Panel Light series gives buyers a scalable platform with consistent materials and appearance across every size. It simplifies specification, reduces installation surprises and provides a clean upgrade path from legacy fluorescent ceilings.

ESPECIFICAÇÃO DO PRODUTO

Especificação	Detalhes
Series	Aluminum frame series LED Panel
Lamp Size	300×450×30mm / 450×450×30mm / 450×900×30mm / 200×1200×30mm / 300×1200×30mm / 600×1200×30mm
LED Qty	18pcs / 36pcs / 72pcs / 30pcs / 45pcs / 90pcs
Potência	36W / 48W / 80W / 48W / 60W / 120W
Temperatura de cor	3000K / 4000K / 6500K
Tensão de entrada	AC85‑265V
Configuration	Laminated iron + PS diffuser plate + aluminum frame

Cenários de aplicação

Open-Plan Offices: The 600×1200 and 300×1200 sizes provide uniform overhead light across workstations and meeting areas.
Retail Stores: Larger panels above aisles and counters create a clean ceiling line that keeps attention on merchandise.
Healthcare and Education: The flat diffuser reduces glare and eye strain during long reading or computer sessions.
